Applications
|
||||
|
Features Universal AC input/Full range (Up to 305VAC) Built-in active PFC function High efficiency up to 90.5% Protections: Short circuit/Over current/Over voltage/Over temperature Cooling by free air convection Fully isolated plastic case Fully encapsulated with IP67 level Class 2 power unit, no FG Built-in 3 in 1 dimming function (1~10Vdc or PWM signal or resistance) Compliance to worldwide safety regulations for lighting Suitable for dry/damp/wet locations |
|||
|
Part Number |
Voltage (max) | Current (amps) | Power (watts) | |
|
LPF-90D-54 |
45V | 2A | 90.18W | |
|
LPF-90D-48 |
45V | 2A |
90.24W |
|
| LPF-90D-42 | 42V | 2.15A |
90.3W |
|
|
LPF-90D-36 |
36V | 2.5A | 90W | |
| LPF-90D-30 | 30V | 3A |
90W |
|
|
LPF-90D-24 |
24V | 4A | 90W | |
| LPF-90D-20 | 20V | 4.5A |
90W |
|
| LPF-90D-15 | 15V | 5A |
75W |
|
