Applications
|
|||||
|
Features Universal AC input/Full range (Up to 305VAC) Built-in active PFC function High efficiency up to 90.5% Protections: Short circuit/Over current/Over voltage/Over temperature Cooling by free air convection Fully isolated plastic case Fully encapsulated with IP67 level Class 2 power unit, no FG Compliance to worldwide safety regulations for lighting Suitable for dry/damp/wet locations |
||||
|
Part Number |
Voltage (max) | Current (amps) | Power (watts) | ||
|
LPF-90-15 |
15V |
5A |
75W |
||
|
LPF-90-20 |
20V | 4.5A | 90W | ||
| LPF-90-24 | 24V | 4A |
90W |
||
|
LPF-90-30 |
30V | 3A | 90W | ||
| LPF-90-36 | 36V | 2.5A |
90W |
||
|
LPF-90-42 |
42V | 2.15A | 90.3W | ||
| LPF-90-48 | 48V | 2A |
90.24W |
||
| LPF-90-54 | 54V | 2A |
90.18W |
||
