Features Universal AC input / Full range Built-in active PFC function, PF>95 Short circuit/Over load/Over voltage Protection Battery low/battery polarity protections Cooling by free air convection 100% full load burn-in test Fixed switching frequency at PFC 67KHz, PWM 134KHz UPS Function |
| Model No | Voltage (Max) | Current (Amps) | Power (Watts) |
| ADD-155A | 14V | 10A | 153W |
| 5V | 3A | ||
| 13.3V | 0.5A | ||
| ADD-155B | 28V | 4.5A | 153W |
| 5V | 3A | ||
| 27.1V | 0.5A | ||
| ADD-155C | 54V | 2.3A | 150W |
| 5V | 3A | ||
| 54V | 0.2A | ||
 |
 |
||
