Features
3 Pole AC inlet IEC320-C14
Built-in active PFC function, PF>0.95
Protections: Short circuit/Overload/Over voltage/ Over temperature
High Power density
Fully enclosed plastic case
Approvals: UL / CUL / CB
No load power consumption <0.5w
ZCS / ZVS technology to reduce power dissipation.
Part Number Voltage Current Power
AS-120P-12 12V 8.4A 100W
AS-120P-15 15V 6.7A 100W
AS-120P-20 20V 6A 120W
AS-120P-24 24V 5A 120W
AS-120P-48 48V 2.5A 120W


Specification

Input Voltage                                              90 ~ 264VAC 127 ~ 370V
Input Frequency                                         47 ~ 63Hz
Power Factor                                              PF >0.95/230VAC PF >0.98/115VAC
at full load typically
Inrush Current                                            120A/230VAC
AC Current                                                 1.4A/115VAC 0.7A/230VAC
Leakage Current                                        <1mA / 240VAC
Setup, Rise Time                                       3000ms, 80ms at full load
Over Load Protection                                 105 ~ 135% rated output power
Hiccup mode                                              recovers automatically after fault condition is removed
Over Voltage Protection                            Shut down o/p voltage, re-power on to recover
Storage Temperature, Humidity                -20°C ~ +85°C , 10 ~ 95% RH
Temp. Coefficient`                                     ±0.03% /°C (0 ~ 50°C)
Withstand Voltage                                      I/P-O/P:4.25KVDC
Life                                                             Average life expectancy of 6 years (12 hours / day, 70% load, 115VAC)
DC Plug                                                     20~48V Output: 2.5 x 5.5 x 11mm, centre positive
                                                                  12~15V Output: 4 pin locking type din
DC Cable                                                  120cm of SPT-1, 16AWG 2 core
